hp-Technik bypass oil valve B-GHG-E/2 2210005

SKU 2210005 Model B-GHG-E/2 Brand hp-Technik

Photos

Key specifications

Maximum viscosity	450 mm2/sec
Supply	300–6000 l/h
Maximum pressure	9 bar
Maximum temperature	150 °C
Ambient temperature	-10 to +90
Storage temperature	-10 to +60

all specifications (6) ↓

1238.63 EUR

1126.03EUR

in stock · 3

incl. 21% VAT · 930.60 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This bypass oil valve is installed in the oil circuit between the pump and nozzle assembly, diverting excess fuel back to the tank or pump inlet to stabilize pressure. It handles flows from 300 to 6000 l/h, pressures up to 9 bar, temperatures up to 150 °C, viscosity up to 450 mm2/sec. Ambient range is -10 to +90 °C, storage -10 to +60 °C. It is suitable for single-pipe systems requiring recirculation.

Further details

Adjustment mechanism	screw and one of five springs
Adjustment method	Screw and one of five springs
Application	Single-pipe and two-pipe oil heating systems
Construction type	compact solution for variable flow systems
Design features	pressure relief and flow regulator; relieves excess pressure from line P to return line T; pressure adjusted via screw and one of five springs
Temperature	max. 150 °C

Choosing and fitting

For this type of valve, verify the hydraulic configuration (single-pipe or two-pipe), required capacity and pressure range. The connection threads and shaft orientation must match the mounting pattern on the pump body. Before ordering, compare opening pressure and flow characteristics with pump output and nozzle rating. Also check that the valve's pressure adjustment range (via screw and spring selection) suits the system.

Signs of failure

Common failure modes include leaking seals, blocked bypass ports, or a stuck regulating piston. This causes unstable firing rates, poor cut-off, or pump cavitation. Check seals and ports for blockage and ensure the piston moves freely.

All specifications

Maximum viscosity	450 mm2/sec
Supply	300–6000 l/h
Maximum pressure	9 bar
Maximum temperature	150 °C
Ambient temperature	-10 to +90
Storage temperature	-10 to +60

Part numbers

SKU	2210005
Additional article	543.322.001
Model	B-GHG-E/2
