hp-Technik bypass oil valve B-P-E/2 2210000

SKU 2210000 Model B-P-E/2 Brand hp-Technik

Photos

Key specifications

Maximum pressure	9 bar
Maximum viscosity	450 mm2/sec
Supply	6–120 l/h
Maximum temperature	150 °C
Ambient temperature	-10–90 °C
Storage temperature	-10–60 °C
Supply flow rate	6-120
Adjustment feature	adjustment screw
Pressure settings	five

all specifications (9) ↓

399.30 EUR

363.00EUR

in stock · 1

incl. 21% VAT · 300.00 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This bypass oil valve stabilizes or limits system pressure by continuously diverting excess fluid from the discharge line to the return line. It features an adjustment screw and interchangeable springs with five pressure settings. The valve handles supply rates from 6 to 120 l/h at a maximum pressure of 9 bar. Maximum viscosity is 450 mm²/sec, and maximum temperature is 150 °C. Ambient temperature range is -10 to 90 °C, with storage temperature from -10 to 60 °C.

Further details

Ambient temperature	-10 to + 90 °C
Function	regulate pressure in discharge line by diverting excess fluid to return line
Storage temperature	-10 to + 60 °C
Temperature	max. 150 °C

All specifications

Maximum pressure	9 bar
Maximum viscosity	450 mm2/sec
Supply	6–120 l/h
Maximum temperature	150 °C
Ambient temperature	-10–90 °C
Storage temperature	-10–60 °C
Supply flow rate	6-120
Adjustment feature	adjustment screw
Pressure settings	five

Part numbers

SKU	2210000
Additional article	543.322.028
Model	B-P-E/2
