Danfoss Oil nozzle 030B0059

Key specifications

Spray angle	45 °
Spray pattern	B
Body material	brass
Net weight	0.032 kg
Gross weight	0.033 kg
Fuel	oil
Application	household and industrial high-pressure burners
Shape	conical
Capacity	1.25 gallons/hour
Safety valve	no
Nozzle type	od b
Maintenance requirement	regular maintenance and periodic replacement
Filter type	sinter
Function - fuel spraying	sprays fuel into fine droplets
Function - emission reduction	reduces emissions
Combustion characteristics	efficient and controlled fuel combustion
Function - fuel economy	maximizes combustion efficiency
Capacity in kg per hour	4.71 kg/h

Spray angle

45 °

Spray pattern

Body material

brass

Net weight

0.032 kg

Gross weight

0.033 kg

Fuel

oil

Application

household and industrial high-pressure burners

Shape

conical

Capacity

1.25 gallons/hour

Safety valve

Nozzle type

od b

Maintenance requirement

regular maintenance and periodic replacement

Filter type

sinter

Function - fuel spraying

sprays fuel into fine droplets

Function - emission reduction

reduces emissions

Combustion characteristics

efficient and controlled fuel combustion

Function - fuel economy

maximizes combustion efficiency

Capacity in kg per hour

4.71 kg/h

all specifications (18) ↓

Description

The Danfoss oil nozzle with SKU 030B0059 is a replacement nozzle for household and industrial high-pressure burners operating on oil. It has a conical brass body and a spray angle of 45 degrees, with a spray pattern designated B. This nozzle delivers a fuel capacity of 1.25 gallons per hour (4.71 kg/h). It sprays fuel into fine droplets to support efficient and controlled combustion, which in turn reduces emissions and maximizes combustion efficiency. The nozzle contains a sinter filter and requires regular maintenance and periodic replacement as part of burner upkeep.

All specifications

Spray angle	45 °
Spray pattern	B
Body material	brass
Net weight	0.032 kg
Gross weight	0.033 kg
Fuel	oil
Application	household and industrial high-pressure burners
Shape	conical
Capacity	1.25 gallons/hour
Safety valve	no
Nozzle type	od b
Maintenance requirement	regular maintenance and periodic replacement
Filter type	sinter
Function - fuel spraying	sprays fuel into fine droplets
Function - emission reduction	reduces emissions
Combustion characteristics	efficient and controlled fuel combustion
Function - fuel economy	maximizes combustion efficiency
Capacity in kg per hour	4.71 kg/h
