Danfoss Oil nozzle 030B0085

SKU 030B0085 Brand Danfoss

Photos

Key specifications

Flow rate	10 GPH
Spray angle	45 °
Spray pattern	b
Body material	brass
Net weight	0.032 kg
Gross weight	0.033 kg
Shape	conical
Operating principle	liquid dispersion into small droplets
Application - Oil burners	oil burners
Capacity	10 gallons/hour
Safety valve	no
Catalogue article numbers	327.892.080
Nozzle type	od b
Filter type	sinter
Function - fuel spraying	spraying fuel
Function - emission reduction	reducing emissions
Combustion characteristics	fuel combustion efficiency
Function - fuel economy	saving energy
Function - fuel air mixing	mixing fuel with air

all specifications (19) ↓

21.16 EUR

19.24EUR

in stock · 10

incl. 21% VAT · 15.90 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This oil nozzle is designed for oil burners, spraying fuel before it enters the combustion chamber. It operates by dispersing liquid into small droplets under pressure. The nozzle has a flow rate of 10 GPH, a 45° spray angle, and a spray pattern marked 'B'. It is made of brass, has a conical shape, and includes a sintered filter. The component supports efficient fuel-air mixing, stable combustion, energy saving, and reduced emissions. Net weight is 0.032 kg, gross weight 0.033 kg.

Further details

Application	heating boilers, gas stoves, aircraft engines

All specifications

Flow rate	10 GPH
Spray angle	45 °
Spray pattern	b
Body material	brass
Net weight	0.032 kg
Gross weight	0.033 kg
Shape	conical
Operating principle	liquid dispersion into small droplets
Application - Oil burners	oil burners
Capacity	10 gallons/hour
Safety valve	no
Catalogue article numbers	327.892.080
Nozzle type	od b
Filter type	sinter
Function - fuel spraying	spraying fuel
Function - emission reduction	reducing emissions
Combustion characteristics	fuel combustion efficiency
Function - fuel economy	saving energy
Function - fuel air mixing	mixing fuel with air

Part numbers

SKU	030B0085
Additional article	327.892.080
