Danfoss Oil nozzle 030B0093

This brass oil nozzle is a precision consumable part for a fuel-oil burner. Through fuel atomization it produces a conical 45° spray pattern designated B, supporting efficient combustion while saving energy and reducing emissions. It has no safety valve. Net weight is 0.026 kg and gross weight is 0.027 kg. Type designation is OD B; article numbers are 030B0093 and 327.892.092.

To choose a replacement oil nozzle, check the flow rate, spray angle and spray pattern against the burner data plate or the original fitting. If the burner manufacturer's specification list is not available, compare the markings on the current nozzle. Verify the thread type before ordering, because a nozzle with the correct capacity but the wrong thread or pattern will not fit or burn correctly.

An oil nozzle of this type is a scheduled-service wear item. A worn, contaminated or incorrectly matched nozzle can cause sooting, pulsation, unstable ignition, or poor combustion. If the flame becomes rough or the burner soots up, inspect the nozzle and, if necessary, replace it with one whose flow rate, angle and pattern match the burner nameplate.
