Danfoss Oil nozzle 030B0127

SKU 030B0127 Brand Danfoss

Photos

Key specifications

Flow rate	6 GPH
Spray angle	60 °
Spray pattern	b
Body material	brass
Net weight	0.034 kg
Gross weight	0.035 kg
Fuel	oil
Shape	conical
Application	burners
Application - Oil burners	oil burners
Capacity	6 gallons/hour
Safety valve	no
Catalogue article numbers	327.892.158
Nozzle type	od b
Maintenance requirement	regular maintenance and checking required
Filter type	monel strainer
Capacity in kg per hour	23.35 kg/h

all specifications (17) ↓

21.16 EUR

19.24EUR

in stock · 106

incl. 21% VAT · 15.90 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This is a Danfoss oil nozzle, model 030B0127, intended for oil burners. It has a flow rate of 6 gallons per hour (23.35 kg/h) and a spray angle of 60 degrees with a spray pattern marked 'b'. The nozzle is made of brass and has a conical shape. It features a monel strainer and weighs 0.034 kg net (0.035 kg gross). Regular maintenance and checking are required.

Further details

Design Features	metal housing with a hole or channel
Function Fuel Air Mixing	ensures uniform mixing of fuel with air
Function Fuel Spraying	fuel is sprayed in the combustion chamber
Hole adjustability	size, shape and location of holes adjustable
Operating Principle	disperses fuel into small droplets through nozzle holes

All specifications

Flow rate	6 GPH
Spray angle	60 °
Spray pattern	b
Body material	brass
Net weight	0.034 kg
Gross weight	0.035 kg
Fuel	oil
Shape	conical
Application	burners
Application - Oil burners	oil burners
Capacity	6 gallons/hour
Safety valve	no
Catalogue article numbers	327.892.158
Nozzle type	od b
Maintenance requirement	regular maintenance and checking required
Filter type	monel strainer
Capacity in kg per hour	23.35 kg/h

Part numbers

SKU	030B0127
Additional article	327.892.158
