Danfoss Oil burner nozzle 030B0131

SKU 030B0131 Brand Danfoss

Photos

Key specifications

Spray pattern	semi-solid
Body material	brass
Net weight	0.032 kg
Gross weight	0.034 kg
Fuel	oil
Application	boilers, furnaces and engines
Application - Oil burners	oil burner
Capacity	7.5 gallons/hour
Safety valve	no
Catalogue article numbers	327.892.169
Nozzle type	od b
Shape	conical
Capacity in kg per hour	29.8 kg/h
Filter type	monel strainer
Control features	adjustable fuel supply
Function - fuel spraying	fuel atomization
Operating principle	fuel dispersion

all specifications (17) ↓

21.16 EUR

19.24EUR

in stock · 310

incl. 21% VAT · 15.90 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This is a Danfoss oil burner nozzle, SKU 030B0131, intended for fuel atomization in oil burners used in boilers, furnaces and engines. It has a semi-solid spray pattern and a conical shape, with a capacity of 7.5 gallons per hour (29.8 kg/h). The nozzle is made of brass and weighs 0.032 kg net (0.034 kg gross). It includes a monel strainer filter and operates on the principle of fuel dispersion. No safety valve is fitted.

Further details

Function Fuel Air Mixing	efficient mixing of fuel with air
Function Fuel Dose Adjustment	control the amount of fuel supplied

All specifications

Spray pattern	semi-solid
Body material	brass
Net weight	0.032 kg
Gross weight	0.034 kg
Fuel	oil
Application	boilers, furnaces and engines
Application - Oil burners	oil burner
Capacity	7.5 gallons/hour
Safety valve	no
Catalogue article numbers	327.892.169
Nozzle type	od b
Shape	conical
Capacity in kg per hour	29.8 kg/h
Filter type	monel strainer
Control features	adjustable fuel supply
Function - fuel spraying	fuel atomization
Operating principle	fuel dispersion

Part numbers

SKU	030B0131
Additional article	327.892.169
