Danfoss Oil nozzle 030F3134

SKU 030F3134 Brand Danfoss

Photos

Key specifications

Flow rate	2.25 GPH
Spray pattern	S
Application	Oil-fired burners
Catalogue article numbers	327.892.282
Design features	Precision component
Function - emission reduction	Reduces emissions
Combustion characteristics	Enables complete combustion
Net weight	0.035 kg
Fuel	Fuel oil
Length	40 mm
Width	23 mm
Height	23 mm
Country of origin	Denmark
Installation location	Industrial and domestic systems

all specifications (14) ↓

21.16 EUR

19.24EUR

in stock · 10

incl. 21% VAT · 15.90 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This oil nozzle from Danfoss is a precision component used in oil-fired burners. It is rated at 2.25 GPH and has an S spray pattern, enabling complete combustion and reducing emissions. Its dimensions are 40 mm x 23 mm x 23 mm, with a net weight of 0.035 kg. The component is manufactured in Denmark for installation in industrial and domestic systems.

Further details

Function Fuel Spraying	Atomise fuel oil into a fine spray cone
Maintenance Requirement	Change annually or as part of burner servicing

Choosing and fitting

For this type of oil nozzle, the critical selection parameters are flow rate (in US gallons per hour), spray angle, and spray pattern; these must match the burner's data plate exactly. The nozzle thread size and type also need to be compatible with the burner’s nozzle adaptor. Before ordering, compare the replacement against the original on all three settings. These nozzles are standard consumables and should be replaced annually or during regular burner servicing.

All specifications

Flow rate	2.25 GPH
Spray pattern	S
Application	Oil-fired burners
Catalogue article numbers	327.892.282
Design features	Precision component
Function - emission reduction	Reduces emissions
Combustion characteristics	Enables complete combustion
Net weight	0.035 kg
Fuel	Fuel oil
Length	40 mm
Width	23 mm
Height	23 mm
Country of origin	Denmark
Installation location	Industrial and domestic systems

Part numbers

SKU	030F3134
Additional article	327.892.282
