What does the shop sell?

Spare parts for gas and oil burners and boilers: gas valves, nozzles, ignition electrodes and transformers, pressure switches, flame detectors, fuel pumps, servomotors and burner control boxes.

How large is the catalogue?

Over 100,000 part numbers from every major manufacturer, brought into one structure so that parts from different brands can be compared and replaced.

Can I find a part by its number?

Yes. The order number, the manufacturer model and any supplier code all lead to the same part, so a number from an old invoice or a nameplate is enough.

What if the part is discontinued?

The catalogue records what the manufacturer replaced it with, and which parts from other brands do the same job — together with the conditions that apply.

The company is based in London and ships across the United Kingdom, Europe and the rest of the world.

Is the shop open yet?

The catalogue is being assembled now. The shop opens as soon as it is ready.

Danfoss Oil nozzle 030F4136

Key specifications

Spray angle	45 °
Spray pattern	s
Body material	brass
Net weight	0.034 kg
Gross weight	0.035 kg
Shape	conical
Capacity	2.5 gallons/hour
Safety valve	no
Catalogue article numbers	030F4136; 327.892.110
Nozzle type	od s
Filter type	monel strainer
Application	household and industrial high-pressure burners
Fuel	all types of fuel
Control features	regulating the intensity of combustion
Function - emission reduction	reduces emissions of harmful substances
Function - fuel economy	increases thermal efficiency
Function - fuel air mixing	ensuring optimal fuel-air ratio

Spray angle

45 °

Spray pattern

Body material

brass

Net weight

0.034 kg

Gross weight

0.035 kg

Shape

conical

Capacity

2.5 gallons/hour

Safety valve

Catalogue article numbers

030F4136; 327.892.110

Nozzle type

od s

Filter type

monel strainer

Application

household and industrial high-pressure burners

Fuel

all types of fuel

Control features

regulating the intensity of combustion

Function - emission reduction

reduces emissions of harmful substances

Function - fuel economy

increases thermal efficiency

Function - fuel air mixing

ensuring optimal fuel-air ratio

all specifications (17) ↓

Description

This conical oil nozzle atomizes fuel at a 45° spray angle with a solid spray pattern (type S). Made of brass and fitted with a monel strainer, it delivers a capacity of 2.5 gallons per hour. The nozzle type is OD S. It is intended for use in household and industrial high-pressure burners operating on all types of fuel. By regulating the intensity of combustion, it helps ensure an optimal fuel-air ratio, which increases thermal efficiency and reduces emissions. Its net weight is 0.034 kg and gross weight 0.035 kg.

All specifications

Spray angle	45 °
Spray pattern	s
Body material	brass
Net weight	0.034 kg
Gross weight	0.035 kg
Shape	conical
Capacity	2.5 gallons/hour
Safety valve	no
Catalogue article numbers	030F4136; 327.892.110
Nozzle type	od s
Filter type	monel strainer
Application	household and industrial high-pressure burners
Fuel	all types of fuel
Control features	regulating the intensity of combustion
Function - emission reduction	reduces emissions of harmful substances
Function - fuel economy	increases thermal efficiency
Function - fuel air mixing	ensuring optimal fuel-air ratio
