Danfoss Oil nozzle 030F4152

SKU 030F4152 Brand Danfoss

Photos

Key specifications

Spray angle	45 °
Spray pattern	s
Body material	brass
Net weight	0.034 kg
Gross weight	0.035 kg
Application	household and industrial high-pressure burners
Shape	conical
Capacity	6 gallons/hour
Safety valve	no
Catalogue article numbers	030F4152, 327.892.157
Nozzle type	od s
Filter type	monel strainer
Function - emission reduction	reduce emissions
Combustion characteristics	efficient and controlled combustion
Capacity in kg per hour	23.35 kg/h

all specifications (15) ↓

—price on request

on order

shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This Danfoss oil nozzle is intended for use in household and industrial high-pressure burners. It has a solid (s) spray pattern at 45°, a conical brass body, and a net weight of 0.034 kg (gross 0.035 kg). The nozzle delivers 6 gallons per hour (23.35 kg/h), incorporates a monel strainer, and has no safety valve. Its nozzle type is OD S. The design ensures efficient, controlled combustion and helps reduce emissions.

Further details

Function Fuel Spraying	spraying the fuel into a fine, tiny droplet
Maintenance Requirement	proper maintenance and periodic replacement of fuel injectors are also necessary
Operating Principle	spraying the fuel into a fine, tiny droplet

All specifications

Spray angle	45 °
Spray pattern	s
Body material	brass
Net weight	0.034 kg
Gross weight	0.035 kg
Application	household and industrial high-pressure burners
Shape	conical
Capacity	6 gallons/hour
Safety valve	no
Catalogue article numbers	030F4152, 327.892.157
Nozzle type	od s
Filter type	monel strainer
Function - emission reduction	reduce emissions
Combustion characteristics	efficient and controlled combustion
Capacity in kg per hour	23.35 kg/h

Part numbers

SKU	030F4152
Additional article	327.892.157
