Danfoss Oil nozzle 030F6152

SKU 030F6152 Brand Danfoss

Photos

Key specifications

Flow rate	6 GPH
Spray pattern	s
Body material	brass
Net weight	0.034 kg
Gross weight	0.034 kg
Fuel	oil
Shape	conical
Application - Oil burners	Oil burners
Nozzle type	od s
Capacity	6 gallons/hour
Capacity in kg per hour	23.35 kg/h
Safety valve	no
Catalogue article numbers	030F6152, 327.892.159
Function - fuel dose adjustment	fuel dose adjustment
Function - fuel spraying	fuel spraying
Function - flame formation	flame formation
Function - fuel economy	fuel economy
Function - emission reduction	reducing emissions

all specifications (18) ↓

21.16 EUR

19.24EUR

in stock · 10

incl. 21% VAT · 15.90 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This is a conical brass oil nozzle for oil burners, designed to deliver a metered flow of fuel oil. It has a flow rate of 6 US gallons per hour (23.35 kg/h) and a solid spray pattern (marked 's'). The nozzle performs fuel dose adjustment, fuel spraying, flame formation, fuel economy, and emission reduction. It is intended for use in oil burners and weighs 0.034 kg net and gross. No safety valve is incorporated.

All specifications

Flow rate	6 GPH
Spray pattern	s
Body material	brass
Net weight	0.034 kg
Gross weight	0.034 kg
Fuel	oil
Shape	conical
Application - Oil burners	Oil burners
Nozzle type	od s
Capacity	6 gallons/hour
Capacity in kg per hour	23.35 kg/h
Safety valve	no
Catalogue article numbers	030F6152, 327.892.159
Function - fuel dose adjustment	fuel dose adjustment
Function - fuel spraying	fuel spraying
Function - flame formation	flame formation
Function - fuel economy	fuel economy
Function - emission reduction	reducing emissions

Part numbers

SKU	030F6152
Additional article	327.892.159
