Danfoss Oil nozzle 030F6908
SKU 030F6908
Brand Danfoss
Photos
Key specifications
| Flow rate | 0.5 GPH |
|---|---|
| Spray angle | 60 ° |
| Spray pattern | solid |
| Body material | brass |
| Net weight | 0.033 kg |
| Gross weight | 0.034 kg |
| material | brass |
| Actuator type | nozzle |
| Shape | conical |
| Capacity | 0.5 gallons/hour |
| Safety valve | no |
| Catalogue article numbers | 327.892.018 |
| Nozzle type | OD S |
| Component type | nozzle |
| Device type | oil nozzle |
| Filter type | sinter |
| Capacity in kg per hour | 1.87 kg/h |
| Application description | spray fuel in combustion chamber |
| SKU (English) | 030F6908, 327.892.018 |
| Material type | brass |
| Filter grade | 45 µm |
| Nozzle type marking | S |
| Capacity (GPH) | 0.5 GPH |
| Material | brass |
| Shape | conical |
21.16 EUR
19.24EUR
in stock · 1024
incl. 21% VAT · 15.90 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
The Danfoss Oil nozzle 030F6908 is a brass component designed to spray fuel in the combustion chamber of oil burners. It has a flow rate of 0.5 GPH (1.87 kg/h) and a spray angle of 60 degrees with a solid spray pattern. The nozzle features a conical shape, a sintered filter with a grade of 45 µm, and no safety valve. Its net weight is 0.033 kg, and gross weight is 0.034 kg. The nozzle type is marked as OD S.
Choosing and fitting
When selecting a replacement oil nozzle, ensure the flow rate (GPH), spray angle, and spray pattern match the burner's requirements. The nozzle type (e.g., solid or hollow) and filter grade must also be compatible. Installation involves removing the old nozzle and fitting the new one securely, ensuring proper alignment and torque.
Signs of failure
Common failures include clogging due to debris or carbon buildup, which can cause uneven spray or reduced flow. This may lead to poor combustion, soot formation, or burner shutdown. Regular inspection and cleaning of the nozzle and its filter are recommended to prevent these issues.
All specifications
| Flow rate | 0.5 GPH |
|---|---|
| Spray angle | 60 ° |
| Spray pattern | solid |
| Body material | brass |
| Net weight | 0.033 kg |
| Gross weight | 0.034 kg |
| material | brass |
| Actuator type | nozzle |
| Shape | conical |
| Capacity | 0.5 gallons/hour |
| Safety valve | no |
| Catalogue article numbers | 327.892.018 |
| Nozzle type | OD S |
| Component type | nozzle |
| Device type | oil nozzle |
| Filter type | sinter |
| Capacity in kg per hour | 1.87 kg/h |
| Application description | spray fuel in combustion chamber |
| SKU (English) | 030F6908, 327.892.018 |
| Material type | brass |
| Filter grade | 45 µm |
| Nozzle type marking | S |
| Capacity (GPH) | 0.5 GPH |
| Material | brass |
| Shape | conical |
Part numbers
| SKU | 030F6908 |
|---|---|
| Additional article | 327.892.018 |
