Danfoss Oil nozzle 030F6916

SKU 030F6916 Brand Danfoss

Photos

Key specifications

Flow rate	0.75 GPH
Spray angle	60 °
Spray pattern	s
Body material	brass
Capacity	0.75 gallons/hour
Net weight	0.032 kg
Gross weight	0.032 kg
Shape	conical
Operating principle	Pressure atomization
Application - Oil burners	Oil burners
Safety valve	no
Catalogue article numbers	030F6916, 327.892.038
Nozzle type	od s
Filter type	sinter

all specifications (14) ↓

21.16 EUR

19.24EUR

in stock · 7

incl. 21% VAT · 15.90 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This is an oil nozzle designed for oil burners, used to atomize fuel oil into the combustion chamber for efficient mixing with air. It has a brass conical body and operates by pressure atomization. The nozzle delivers 0.75 GPH and produces a solid spray pattern at a 60° angle. It includes a sintered filter and is not fitted with a safety valve. The net and gross weight are both 0.032 kg.

Further details

Combustion Characteristics	Fuel dispersed into small droplets increasing surface area for better combustion
Design Features	Metal housing with a hole or channel for the passage of fuel
Function - fuel air mixing	Ensure uniform mixing of fuel with air
Function Fuel Spraying	Spray fuel in the combustion chamber to create a combustible cloud
Maintenance Requirement	Regular maintenance and condition check necessary

All specifications

Flow rate	0.75 GPH
Spray angle	60 °
Spray pattern	s
Body material	brass
Capacity	0.75 gallons/hour
Net weight	0.032 kg
Gross weight	0.032 kg
Shape	conical
Operating principle	Pressure atomization
Application - Oil burners	Oil burners
Safety valve	no
Catalogue article numbers	030F6916, 327.892.038
Nozzle type	od s
Filter type	sinter

Part numbers

SKU	030F6916
Additional article	327.892.038
