Danfoss Oil nozzle 030F8910

SKU 030F8910 Brand Danfoss

Photos

Key specifications

Flow rate	0.55 GPH
Spray angle	80 °
Spray pattern	s
Body material	brass
Net weight	0.034 kg
Gross weight	0.035 kg
Fuel	oil
Shape	conical
Capacity	0.55 gallons/hour
Safety valve	no
Nozzle type	od s
Filter type	sinter
Application - Oil burners	oil burner
Function - fuel spraying	even distribution of fuel
Function - fuel dose adjustment	change fuel consumption
Combustion characteristics	optimal combustion

all specifications (16) ↓

21.16 EUR

19.24EUR

in stock · 5

incl. 21% VAT · 15.90 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This is a brass oil nozzle for oil burners, rated at 0.55 US gallons per hour with an 80° spray angle. The spray pattern is solid, designated 'S', and the nozzle has a conical shape. It uses a sintered filter and has no safety valve. The component ensures even fuel distribution and supports optimal combustion. Net weight is 0.034 kg; gross weight is 0.035 kg. Its design allows fuel consumption adjustment to match heating system needs.

Further details

Function - fuel/air mixing	formation of an optimal mixture with air

All specifications

Flow rate	0.55 GPH
Spray angle	80 °
Spray pattern	s
Body material	brass
Net weight	0.034 kg
Gross weight	0.035 kg
Fuel	oil
Shape	conical
Capacity	0.55 gallons/hour
Safety valve	no
Nozzle type	od s
Filter type	sinter
Application - Oil burners	oil burner
Function - fuel spraying	even distribution of fuel
Function - fuel dose adjustment	change fuel consumption
Combustion characteristics	optimal combustion

Part numbers

SKU	030F8910
Additional article	327.892.025
