Delavan Oil nozzle 02400-60B0

The Delavan 02400-60B0 is an oil nozzle designed for use in burners, delivering a capacity of 24 gallons per hour with a spray angle of 60 degrees. It features a B solid-cone spray pattern, which distributes fuel uniformly throughout the complete pattern, ensuring smooth ignition and efficient combustion, particularly in larger burners. This nozzle is identified by SKU 02400-60B0 and article number 345.892.221.

Oil nozzles of this type are selected based on capacity (GPH), spray angle, and spray pattern to match the burner's requirements. When replacing, ensure the nozzle's flow rate and angle correspond to the manufacturer's specifications for the burner. The nozzle threads and dimensions must be compatible with the burner's adapter. Always compare the old nozzle's markings with the new one before installation.

Common failures include clogging due to dirt or debris, which can cause uneven spray, poor combustion, or soot buildup. A worn or damaged nozzle may lead to ignition problems, flame instability, or increased fuel consumption. Check the nozzle for blockages or wear if the burner exhibits these issues.
