Delavan Oil nozzle P0110-60W1

The Delavan Oil nozzle P0110-60W1 is a component for oil burners, designed to deliver fuel at a rate of 1.1 gallons per hour with a spray angle of 60 degrees. It features a W spray pattern, which is neither fully hollow nor solid, making it versatile for various burner air patterns. This nozzle is suitable for use in heating systems and other devices that require precise fuel atomization and combustion control. It operates within a compatibility range of 0.40 to 8.00 gph, with lower flow rates exhibiting a more hollow spray behavior.

When selecting a replacement oil nozzle, ensure that the capacity (GPH), spray angle, and spray pattern match the burner's requirements. The nozzle must be compatible with the burner's air pattern and fuel type. Installation involves removing the old nozzle and installing the new one with proper torque, ensuring no debris enters the fuel line.

Common failure modes for oil nozzles include clogging, which can cause incomplete combustion, soot formation, or a pulsating flame. A worn or damaged nozzle may lead to improper fuel atomization, resulting in poor ignition or unstable flame. Regular inspection and cleaning are recommended to maintain optimal performance.
