Name: Monarch Oil burner nozzle 0986721
Brand: Monarch
SKU: 0986721
Price: 29.04 EUR
Availability: InStock

Key specifications

Flow rate

3 GPH

Spray angle

60 °

Spray pattern

Capacity

3 gal/hr

Operating viscosity

70 ssu (approx. 13 centistokes)

Nozzle type

all specifications (6) ↓

Description

The Monarch Oil burner nozzle 0986721 is a replacement oil nozzle designed for use in oil burners. It has a capacity of 3 gal/hr and a spray angle of 60 degrees. The spray pattern is HO, and it is intended for use with oil having an operating viscosity of 70 ssu (approximately 13 centistokes). This nozzle is suitable for applications requiring a flow rate of 3 GPH.

Further details

Application	key element for ensuring efficient fuel combustion and thermal energy generation
Materials of manufacture	various materials, including metals, ceramics and plastics
Technological innovations	may include ultrasonic or piezoelectric systems

Choosing and fitting

When selecting a replacement oil nozzle of this type, ensure that the capacity (in GPH), spray angle, and spray pattern match the original specifications. The nozzle must be compatible with the burner's operating pressure range and the viscosity of the fuel oil used. Installation involves removing the old nozzle and installing the new one with proper torque, ensuring a secure fit without damaging the threads.

Signs of failure

Common failure modes for oil nozzles include clogging due to debris or carbon buildup, which can cause uneven flame, soot formation, or reduced heating efficiency. A worn or damaged nozzle may result in improper atomization, leading to incomplete combustion and increased fuel consumption. Regular inspection and cleaning or replacement of the nozzle are recommended to maintain optimal burner performance.

All specifications
