Brahma Solenoid valve E7/L*A3C 13191801

The Brahma model E7/L*A3C (SKU 13191801) is a normally closed, quick-release solenoid oil valve for light liquid fuels. Its brass body has a G1/8"F connection and a 1.5 mm nozzle. The coil is for alternating current and is powered at 230 V, 50 Hz, drawing 11 W; the valve opens and closes in ≤1 s. It is rated for 0–20 bar working pressure, 0–60 °C ambient temperature, and a maximum fuel temperature of 80 °C. The unit weighs 0.23 kg, is rated IP65, and is fitted with a three-core IP65 cable.

When ordering a replacement for this kind of solenoid oil valve, check that the supply voltage/frequency, connection thread, pressure range, and maximum fuel temperature match the existing installation. On installation, mount the body so the flow-direction arrow follows the actual flow, fit a suitable filter at the inlet, use a properly sized hex wrench to avoid dislodging the protective shell, and make sure the valve body is grounded according to the applicable electrical standard.
