Honeywell Dinface connector CO020012

The Honeywell Dinface connector CO020012 is a connector component designed for use with Honeywell VR400 series gas valves. It serves as the electrical interface between the valve actuator and the burner control or wiring harness, carrying low-voltage control signals and the mains supply that operates the valve. This connector is matched by pin count, pitch, and keying to ensure proper alignment and contact. It is manufactured by Honeywell and falls under the category of connectors.

Connectors of this type are selected by matching pin count, pin pitch, and keying profile to the specific valve series. Before ordering, confirm the number of pins and the connector series, usually indicated on the valve housing or in its documentation. Verify that the conductor cross-section of the existing cable matches the connector terminals, and that the insulation temperature class is adequate for the ambient conditions. The terminal style (crimp or screw) and cable length must suit the installation layout.

Loose or corroded contacts in this type of connector can reproduce almost any electrical fault symptom, such as intermittent lockout, failure to open the gas valve, or a lost flame signal. Inspect the connector for bent pins, oxidised terminals, or signs of overheating before replacing the valve or the burner control.
