Kromschroder Electrode plug 04115302
SKU 04115302
Brand Kromschroder
Photos
Key specifications
| Shape | straight |
|---|---|
| PBT material | polybutylene terephthalate |
| Temperature fluctuation resistance | high heat resistance |
| Installation ease | simple and quick installation |
| Troubleshooting note | routine check during fault finding |
35.12 EUR
31.93EUR
in stock · 5
incl. 21% VAT · 26.39 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
Kromschroder Electrode plug 04115302 is a straight connector made of polybutylene terephthalate (PBT) with high heat resistance. It is designed for use with Kromschroder FE and FZE series ignition and sensing electrodes, providing a 4 mm connection. The plug ensures simple and quick installation and is intended for routine checks during fault finding.
Further details
| Application area | industrial gas and combination burners, boiler plants, drying chambers, thermal furnaces and other heat-generating equipment |
|---|---|
| Compatibility note | perfectly fits all kromschroder electrodes with 4 mm diameter |
| Fault symptoms | intermittent ignition or false flame signals |
| Function description | provides the electrical link between the electrode and the ignition transformer or burner control, carrying the high-voltage ignition spark or the low-voltage flame signal |
| Ordering verification | use the manufacturer code 04115302 or catalogue article 624.934.003 to order the correct part |
| Replacement considerations | ensure the pin diameter matches the electrode terminal and that the insulation is rated for the temperature and voltage present near the burner |
| Safety standard | compliance with gas equipment safety standards |
Choosing and fitting
Parts of this type are selected by pin diameter, insulation rating, and terminal style. Ensure the pin diameter matches the electrode terminal and that the insulation is rated for the temperature and voltage present near the burner. Mounting forms include straight and angled designs; compare the existing connector's shape and dimensions before ordering.
Signs of failure
A poor contact at this point can cause intermittent ignition or false flame signals. Failure modes include cracking or melting due to heat, leading to electrical leakage or open circuits. Check the connector for visible damage, looseness, or corrosion during routine maintenance.
Fits equipment
Kromschroder FE, FZEKromschroder FE seriesKromschroder FZE series
All specifications
| Shape | straight |
|---|---|
| PBT material | polybutylene terephthalate |
| Temperature fluctuation resistance | high heat resistance |
| Installation ease | simple and quick installation |
| Troubleshooting note | routine check during fault finding |
Part numbers
| SKU | 04115302 |
|---|---|
| Additional article | 624.934.003 |
