Kromschroder Electrode connector 04115306
SKU 04115306
Brand Kromschroder
Photos
Key specifications
| Pin count | matched by pin count |
|---|---|
| Pitch | matched by pitch |
| Keying | matched by keying |
| Terminal type | quick-connect |
| Interference-proof | interference-proof |
| Signal type | low-voltage signals and mains supply |
| Connector class | plugs and connectors |
33.64 EUR
30.58EUR
in stock · 20
incl. 21% VAT · 25.27 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
Kromschroder Electrode connector 04115306 is a straight adapter with a 6 mm connection, designed for use with ignition and flame sensing electrodes. It is interference-proof and belongs to the plugs and connectors category. This connector carries low-voltage signals and mains supply between the burner control board and system components. It is matched by pin count, pitch, and keying, and features a quick-connect terminal type.
Further details
| Fault symptoms | lockouts, false flame signals, erratic ignition |
|---|---|
| Inspection advice | if cable or terminal shows signs of overheating, corrosion or mechanical damage, replace complete connector assembly |
| Replacement considerations | incorrect connector may not lock securely or may cause intermittent contact |
| Selection parameters | number of pins, pitch, keying, conductor cross-section, insulation temperature class, cable length, terminal type |
| Straight adapter | straight adapter with 6 mm connection |
Choosing and fitting
Parts of this type are selected by matching pin count, pitch, and keying to the existing harness and control board receptacle. Before ordering, verify the number of pins, the pitch between contacts, and the physical orientation (keying). Also consider conductor cross-section, insulation temperature class, cable length, and terminal type. Ensure the connector locks securely to avoid intermittent contact.
Signs of failure
Failure of such connectors can cause lockouts, false flame signals, or erratic ignition due to poor contact. Overheating, corrosion, or mechanical damage may be visible on the cable or terminal. If any of these signs are present, replacing the complete connector assembly is preferred over repair.
All specifications
| Pin count | matched by pin count |
|---|---|
| Pitch | matched by pitch |
| Keying | matched by keying |
| Terminal type | quick-connect |
| Interference-proof | interference-proof |
| Signal type | low-voltage signals and mains supply |
| Connector class | plugs and connectors |
Part numbers
| SKU | 04115306 |
|---|---|
| Additional article | 210.106.001 |
