Kromschroder Angular connector 04115308

The Kromschroder 04115308 is an angular connector (right-angle boot) designed for use in gas burners. It connects a high-voltage cable to an ignition electrode or flame sensor, ensuring stable spark generation. The connector has an optimal size of ø 4 mm and includes a built-in resistor to reduce electromagnetic interference. It withstands temperature and mechanical loads typical of burner operations. This item is of original Kromschroder quality.

Parts of this type are selected by confirming the series and number of contacts, conductor cross-section, insulation temperature class, and terminal style (crimp or screw). The physical dimensions and locking mechanism must match the counterpart on the control board or component. The angular form factor should be checked for clearance, as orientation may differ from a straight connector. Ensure the connector body, contacts, and any sealing gasket match your system's wiring and environmental requirements.

Poor contact at any connector interface can produce erratic faults that mimic a defective board, sensor, or actuator. Symptoms may include intermittent ignition failure, false flame signals, or unexpected shutdowns. Check the connector for loose connections, corrosion, or damaged contacts. Verify that the connector is properly seated and that the locking mechanism is engaged.
