Kromschroder Gas pressure switch DG50B-5 32Z 84447202

Key specifications

Control features	Set point adjustment via handwheel
Design features	Microswitch with switching contact
Diaphragm material	NBR
Lower housing material	AlSi 12
Protection class (IP)	1
Connection thread	M16 x 1.5
Electrical connection	Screw terminals
Weight	0.321 g
Construction type	Diaphragm pressure switch

Control features

Set point adjustment via handwheel

Design features

Microswitch with switching contact

Diaphragm material

NBR

Lower housing material

AlSi 12

Protection class (IP)

Connection thread

M16 x 1.5

Electrical connection

Screw terminals

Weight

0.321 g

Construction type

Diaphragm pressure switch

all specifications (9) ↓

Description

This item is a diaphragm-type gas pressure switch used to monitor pressure changes in gases or air. The set point is adjusted by a handwheel. A microswitch with a switching contact performs the switching action. The diaphragm is made of NBR, and the lower housing is made of AlSi 12. The electrical connection is via screw terminals. It has protection class 1 and an M16 x 1.5 connection thread.

Body material	Glass fibre reinforced PBT plastic with low gas release
Gas type	natural gas, town gas, LPG (gaseous), flue gas, biogas (max. 0.1 %-by-vol. H2S) and air

Body material

Glass fibre reinforced PBT plastic with low gas release

Gas type

natural gas, town gas, LPG (gaseous), flue gas, biogas (max. 0.1 %-by-vol. H2S) and air

Choosing and fitting

Parts of this type are selected by the process connection thread, the electrical connection style, and the pressure range required by the application. Before ordering, measure the existing port thread and cable diameter, and confirm that the switch’s enclosure rating suits the installation environment. Mounting is normally done directly into the pressure tap, with the electrical wiring connected to the screw terminals. Also ensure the medium and ambient temperature limits cover the installation site.

All specifications

Control features	Set point adjustment via handwheel
Design features	Microswitch with switching contact
Diaphragm material	NBR
Lower housing material	AlSi 12
Protection class (IP)	1
Connection thread	M16 x 1.5
Electrical connection	Screw terminals
Weight	0.321 g
Construction type	Diaphragm pressure switch
