Kromschroder Gas pressure switch DG6U-3Z 84447262

SKU 84447262 Model DG6U-3Z Brand Kromschroder

Photos

Key specifications

Construction type	Diaphragm
Operating principle	Differential
Diaphragm material	NBR (silicone-free)
Lower housing material	AlSi12
Protection class (IP)	1
Wire diameter	0.5 mm
Connection thread	M16 x 1.5
Electrical connection	Screw terminals

all specifications (8) ↓

209.30 EUR

190.27EUR

in stock · 3

incl. 21% VAT · 157.25 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This gas pressure switch operates on the differential pressure principle with a diaphragm construction. It is designed for monitoring pressure changes in gas or air environments. The electrical connection is made via screw terminals, and the connection thread is M16 x 1.5. The diaphragm is made of silicone-free NBR, and the lower housing is made of AlSi12. It is rated protection class 1 and accepts wire diameters of 0.5 mm.

Further details

Housing material	Glass fibre reinforced PBT plastic with low gas release

All specifications

Construction type	Diaphragm
Operating principle	Differential
Diaphragm material	NBR (silicone-free)
Lower housing material	AlSi12
Protection class (IP)	1
Wire diameter	0.5 mm
Connection thread	M16 x 1.5
Electrical connection	Screw terminals

Part numbers

SKU	84447262
Additional article	624.214.220
Model	DG6U-3Z
