Kromschroder Gas pressure switch DG6UG-3K2 84447277

SKU 84447277 Model DG6UG-3K2 Brand Kromschroder

Photos

Key specifications

Certification	CE-0085AP0467
Setting range	0.4–6 mbar
Design features	gold-plated contacts
Ingress protection	IP54
Pilot lamp voltage	24 V AC/DC
Safety standard	EN 13611:2015+AC:2016, EN 1854:2010

all specifications (6) ↓

257.26 EUR

233.87EUR

in stock · 6

incl. 21% VAT · 193.28 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This is a Kromschroder DG6UG-3K2 gas pressure switch (SKU 84447277). It monitors increasing and decreasing gas or air pressure within an adjustable range of 0.4 to 6 mbar. The switch is fitted with gold-plated contacts and an IP54 enclosure. A green/red pilot lamp indicates status at 24 V AC/DC. It is certified under CE-0085AP0467 and meets EN 13611:2015+AC:2016 and EN 1854:2010.

Further details

Electrical connection	screw terminals and M16 cable gland
Operating principle	rising positive pressure (gas/air), negative pressure (air), differential pressure (air-air)

All specifications

Certification	CE-0085AP0467
Setting range	0.4–6 mbar
Design features	gold-plated contacts
Ingress protection	IP54
Pilot lamp voltage	24 V AC/DC
Safety standard	EN 13611:2015+AC:2016, EN 1854:2010

Part numbers

SKU	84447277
Additional article	624.214.221
Model	DG6UG-3K2
