Fema Pressure switch DPTE102S

The Fema DPTE102S is a pressure switch designed for use in ventilation systems to monitor the condition of filters, dampers, and fans by measuring pressure drop. It operates with a 4...20 mA (2-wire) output signal and requires a supply voltage of 18–30 V. The device functions within an operating temperature range of 0–50 °C and can be stored at temperatures from -40 to 85 °C. It has a response time of 1 second, with the possibility of up to 100 ms. The protection class is IP54, and it is suitable for use with air and non-aggressive gases.

When selecting a pressure switch of this type, ensure that the output signal type (e.g., 4...20 mA) and supply voltage match the control system. The operating temperature range and protection class must be compatible with the installation environment. The medium (air or non-aggressive gas) and the pressure range should be verified against the application requirements. Installation involves connecting the pipeline (typically a 6 mm tube) and electrical wiring to a screw terminal block, ensuring proper sealing to maintain the IP54 rating.

Common failure modes for pressure switches of this kind include drift in the output signal, which can cause inaccurate pressure readings, or complete failure to switch, leading to improper fan or damper operation. Symptoms may include the ventilation system not responding to filter clogging or damper position changes. To diagnose, check the output signal against a known pressure source and inspect the electrical connections for corrosion or loose terminals. Also, verify that the sensing port is not blocked or contaminated.
