Kromschroder Gas pressure switch DG360C8D-5S 84448751
SKU 84448751
Model DG360C8D-5S
Brand Kromschroder
Photos
Key specifications
| Connection thread | R 1/4 external thread |
|---|---|
| Body material | glass fibre reinforced PBT plastic |
| Diaphragm material | NBR |
| Function | control of overpressure level |
| Adjustment method | adjustable on hand wheel |
| Lower housing material | AlSi12 |
| Silicone-free | silicone-free |
| Low gas release | with low gas release |
| Construction type | diaphragm pressure switch |
| Application | boiler systems |
| Electrical connection | 4-pin plug |
| Switching function | switches with falling pressure |
| Certification | RoHS compliant pursuant to 2002/95/EC |
| Service life | 10 years |
| EU version | EU version |
| Adjusting range | 100–360 mbar |
| Safety class | 1 |
| Weight | 100 g |
| Cover screw | 45 Ncm |
| Socket | 45 Ncm |
| Storage temperature | -20–40 °C |
| Maximum medium and ambient temperatures | -20–70 °C |
154.07 EUR
140.06EUR
in stock · 1
incl. 21% VAT · 115.75 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This Kromschroder gas pressure switch, model DG360C8D-5S (SKU 84448751), is a diaphragm pressure switch designed for boiler systems. It controls overpressure level and switches with falling pressure. The adjusting range is 100–360 mbar, adjustable on a hand wheel. It features R 1/4 external thread, 4-pin plug electrical connection, glass fibre reinforced PBT plastic body with AlSi12 lower housing, and an NBR diaphragm. The switch is silicone-free, has low gas release, is RoHS compliant per 2002/95/EC, and weighs 100 g. It operates at medium and ambient temperatures from –20 to 70 °C, with storage temperature from –20 to 40 °C, and has a service life of 10 years.
Further details
| Diaphragm | NBR |
|---|---|
| Enclosure | IP 54 pursuant to DIN EN 60529 with standard socket pursuant to DIN EN 175301-803, IP 00 with AMP plug |
| Gas type | natural gas, town gas, LPG (gaseous), flue gas, biogas (max. 0.1 %-by-vol. H2S) and air |
| Housing | glass fibre reinforced PBT plastic with low gas release |
| Lower housing section | AlSi 12 |
| Protection Class | IP54 (with standard socket), IP00 (with Amp plug) |
Fits equipment
All specifications
| Connection thread | R 1/4 external thread |
|---|---|
| Body material | glass fibre reinforced PBT plastic |
| Diaphragm material | NBR |
| Function | control of overpressure level |
| Adjustment method | adjustable on hand wheel |
| Lower housing material | AlSi12 |
| Silicone-free | silicone-free |
| Low gas release | with low gas release |
| Construction type | diaphragm pressure switch |
| Application | boiler systems |
| Electrical connection | 4-pin plug |
| Switching function | switches with falling pressure |
| Certification | RoHS compliant pursuant to 2002/95/EC |
| Service life | 10 years |
| EU version | EU version |
| Adjusting range | 100–360 mbar |
| Safety class | 1 |
| Weight | 100 g |
| Cover screw | 45 Ncm |
| Socket | 45 Ncm |
| Storage temperature | -20–40 °C |
| Maximum medium and ambient temperatures | -20–70 °C |
Part numbers
| SKU | 84448751 |
|---|---|
| Additional article | 624.214.243 |
| Model | DG360C8D-5S |
