Kromschroder Gas pressure switch DG40VC1-5WG /B 75454579

SKU 75454579 Model DG40VC1-5WG /B Brand Kromschroder

Photos

Key specifications

Setting range	5–40 mbar
Body material	glass fibre reinforced PBT plastic
Electrical connection	4-pin plug, without socket
Weight	90 g
Adjusting range	5–40 mbar
Safety class	1
Diaphragm material	NBR
Adjustment method	hand wheel
Lower housing material	AlSi 12
Silicone-free	yes
Low gas release	yes
Pressure type	differential
Line entrance thread	M16 x 1.5
Line diameter	0.5–1.8 mm
Valvario controls connection	at the bottom
Pressure tap side	on the plug side
Construction type	diaphragm pressure switch
Max test pressure	temporarily maximum

all specifications (18) ↓

236.71 EUR

215.19EUR

in stock · 2

incl. 21% VAT · 177.84 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This Kromschroder diaphragm pressure switch (SKU 75454579) is a differential pressure switch with an adjusting range of 5–40 mbar. The set point is adjusted by means of a hand wheel. The glass-fibre reinforced PBT plastic housing has a lower housing section of AlSi 12, and the NBR diaphragm is silicone-free. The switch is electrically connected via a 4-pin plug (without socket), and the line entrance is M16 x 1.5 for wire diameters of 0.5–1.8 mm. It weighs 90 g and meets safety class 1.

Further details

Function	monitor pressure in gas, air and biomethane
Gas type	natural gas, town gas, LPG (gaseous), flue gas, biogas and air
Media Compatibility	natural gas, town gas, LPG (gaseous), flue gas, biogas and air

All specifications

Setting range	5–40 mbar
Body material	glass fibre reinforced PBT plastic
Electrical connection	4-pin plug, without socket
Weight	90 g
Adjusting range	5–40 mbar
Safety class	1
Diaphragm material	NBR
Adjustment method	hand wheel
Lower housing material	AlSi 12
Silicone-free	yes
Low gas release	yes
Pressure type	differential
Line entrance thread	M16 x 1.5
Line diameter	0.5–1.8 mm
Valvario controls connection	at the bottom
Pressure tap side	on the plug side
Construction type	diaphragm pressure switch
Max test pressure	temporarily maximum

Part numbers

SKU	75454579
Additional article	624.214.244
Model	DG40VC1-5WG /B
