What does the shop sell?

Spare parts for gas and oil burners and boilers: gas valves, nozzles, ignition electrodes and transformers, pressure switches, flame detectors, fuel pumps, servomotors and burner control boxes.

How large is the catalogue?

Over 100,000 part numbers from every major manufacturer, brought into one structure so that parts from different brands can be compared and replaced.

Can I find a part by its number?

Yes. The order number, the manufacturer model and any supplier code all lead to the same part, so a number from an old invoice or a nameplate is enough.

What if the part is discontinued?

The catalogue records what the manufacturer replaced it with, and which parts from other brands do the same job — together with the conditions that apply.

The company is based in London and ships across the United Kingdom, Europe and the rest of the world.

Is the shop open yet?

The catalogue is being assembled now. The shop opens as soon as it is ready.

Kromschroder Gas pressure switch DG50U-6 84447351

Photos

Key specifications

Body material	glass fibre reinforced PBT plastic
Low gas release	yes
Adjusting range	2.5–50 mbar
Electrical connection	4-pin plug, with socket
Construction type	diaphragm pressure switch
Diaphragm material	NBR
Silicone-free	yes
Lower housing material	AlSi12
Line diameter	0.5–1.8 mm
Line entrance thread	m16 x 1.5
Adjustment method	handwheel
Switching element	microswitch with a switching contact
Screw terminals	screw terminals

Body material

glass fibre reinforced PBT plastic

Low gas release

yes

Adjusting range

2.5–50 mbar

Electrical connection

4-pin plug, with socket

Construction type

diaphragm pressure switch

Diaphragm material

NBR

Silicone-free

yes

Lower housing material

AlSi12

Line diameter

0.5–1.8 mm

Line entrance thread

m16 x 1.5

Adjustment method

handwheel

Switching element

microswitch with a switching contact

Screw terminals

screw terminals

all specifications (13) ↓

Description

This diaphragm pressure switch monitors gas or air pressure and has an adjusting range of 2.5–50 mbar. It is silicone-free, with an NBR diaphragm and a body of glass fibre reinforced PBT plastic; the lower housing is AlSi12, and the design is low gas release. Electrical connection is through a 4-pin plug with socket and screw terminals. The switching element is a microswitch with one switching contact, and the set point is adjusted with a handwheel. The line entrance thread is M16 x 1.5, and the line diameter ranges from 0.5 to 1.8 mm.

Function	monitor pressure changes in gases or air
Pressure Type	rising positive pressure (gas/air), negative pressure (air), differential pressure (air-air)

Function

monitor pressure changes in gases or air

Pressure Type

rising positive pressure (gas/air), negative pressure (air), differential pressure (air-air)

All specifications

Body material	glass fibre reinforced PBT plastic
Low gas release	yes
Adjusting range	2.5–50 mbar
Electrical connection	4-pin plug, with socket
Construction type	diaphragm pressure switch
Diaphragm material	NBR
Silicone-free	yes
Lower housing material	AlSi12
Line diameter	0.5–1.8 mm
Line entrance thread	m16 x 1.5
Adjustment method	handwheel
Switching element	microswitch with a switching contact
Screw terminals	screw terminals
