Kromschroder Gas pressure switch DG60VC4-6WG 24Z 84448271

SKU 84448271 Model DG60VC4-6WG 24Z Brand Kromschroder

Photos

Key specifications

Body material	glass fibre reinforced PBT plastic
Pressure type	differential pressure
Certification	RoHS compliant pursuant to 2002/95/EC
Maximum medium and ambient temperatures	-20–70 °C
Storage temperature	-20–40 °C
Construction type	diaphragm pressure switch
Diaphragm material	NBR
Silicone-free	yes
Low gas release	yes
Lower housing material	AlSi12
Safety class	1
Weight	83 g
Cover screw	45 Ncm
Socket	45 Ncm

all specifications (14) ↓

243.76 EUR

221.60EUR

in stock · 1

incl. 21% VAT · 183.14 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This differential pressure switch is a diaphragm-type pressure switch with a silicone-free NBR diaphragm. The body is made of glass fibre reinforced PBT plastic with low gas release, and the lower housing is AlSi12. It is RoHS compliant pursuant to 2002/95/EC and belongs to safety class 1. The switch weighs 83 g. It is rated for medium and ambient temperatures from -20 to 70 °C and for storage from -20 to 40 °C.

Further details

Electrical Connection	standard socket per DIN EN 175301-803; AMP plug
Media Compatibility	natural gas, town gas, lpg (gaseous), flue gas, biogas (max. 0.1 %-by-vol. h2s) and air
Protection Class	IP54 (DIN EN 60529) with standard socket; IP00 with AMP plug

All specifications

Body material	glass fibre reinforced PBT plastic
Pressure type	differential pressure
Certification	RoHS compliant pursuant to 2002/95/EC
Maximum medium and ambient temperatures	-20–70 °C
Storage temperature	-20–40 °C
Construction type	diaphragm pressure switch
Diaphragm material	NBR
Silicone-free	yes
Low gas release	yes
Lower housing material	AlSi12
Safety class	1
Weight	83 g
Cover screw	45 Ncm
Socket	45 Ncm

Part numbers

SKU	84448271
Additional article	624.214.242
Model	DG60VC4-6WG 24Z
