Kromschroder Gas pressure switch DG60VC5-5W 84448230
SKU 84448230
Model DG60VC5-5W
Brand Kromschroder
Photos
Key specifications
| Connection thread | RP 1/4 internal thread |
|---|---|
| Protection class (IP) | IP00 |
| Body material | glass fibre reinforced PBT plastic |
| Electrical connection | 4-pin plug, without socket |
| Weight | 83 g |
| Adjusting range | 10–60 mbar |
| Safety class | 1 |
| Cover screw | 45 Ncm |
| Socket | 45 Ncm |
| Storage temperature | -20–40 °C |
| Maximum medium and ambient temperatures | -20–70 °C |
| Diaphragm material | NBR |
| Adjustment method | adjustable on hand wheel |
| Lower housing material | AlSi 12 |
| Silicone-free | silicone-free |
| Low gas release | low gas release |
| Switching function | switches with falling pressure |
| EU version | EU version |
| Construction type | diaphragm pressure switch |
| Certification | RoHS compliant pursuant to 2002/95/EC |
| Change-over contact | change-over contact |
| Ambient temperature, max | 70 °C |
| Ambient temperature, min | -20 °C |
177.53 EUR
161.39EUR
in stock · 3
incl. 21% VAT · 133.38 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This diaphragm gas pressure switch monitors gas pressure and switches an electrical contact when the pressure falls below an adjustable setpoint. Its adjusting range is 10–60 mbar, and it is set by a hand wheel. It has an RP 1/4 internal thread for the pressure connection and a change-over contact via a 4-pin plug without socket. The diaphragm is made of NBR, the housing of glass-fibre reinforced PBT plastic, and the lower housing of AlSi 12; it is silicone-free and has low gas release. It is rated for ambient and medium temperatures from -20 to 70 °C, storage from -20 to 40 °C, protection class IP00, safety class 1, and weighs 83 g.
Further details
| Media Compatibility | natural gas, town gas, LPG (gaseous), flue gas, biogas (max. 0.1 %-by-vol. H2S) and air |
|---|
All specifications
| Connection thread | RP 1/4 internal thread |
|---|---|
| Protection class (IP) | IP00 |
| Body material | glass fibre reinforced PBT plastic |
| Electrical connection | 4-pin plug, without socket |
| Weight | 83 g |
| Adjusting range | 10–60 mbar |
| Safety class | 1 |
| Cover screw | 45 Ncm |
| Socket | 45 Ncm |
| Storage temperature | -20–40 °C |
| Maximum medium and ambient temperatures | -20–70 °C |
| Diaphragm material | NBR |
| Adjustment method | adjustable on hand wheel |
| Lower housing material | AlSi 12 |
| Silicone-free | silicone-free |
| Low gas release | low gas release |
| Switching function | switches with falling pressure |
| EU version | EU version |
| Construction type | diaphragm pressure switch |
| Certification | RoHS compliant pursuant to 2002/95/EC |
| Change-over contact | change-over contact |
| Ambient temperature, max | 70 °C |
| Ambient temperature, min | -20 °C |
Part numbers
| SKU | 84448230 |
|---|---|
| Additional article | 624.214.228 |
| Model | DG60VC5-5W |
