Kromschroder Air pressure switch DL5A-3Z 84447478
SKU 84447478
Model DL5A-3Z
Brand Kromschroder
Photos
Key specifications
| Body material | glass fibre reinforced PBT plastic |
|---|---|
| Weight | 254 g |
| Cover screw | 65 Ncm |
| Socket | 65 Ncm |
| Low gas release | yes |
| Construction type | diaphragm pressure switch |
| Micro switch standard | EN 61058-1 |
| Safety class | II to VDE 0106-1 |
| Diaphragm system | tempered LSR diaphragm system |
| Designed lifetime | 10 years |
| Standards | EN 13611:2015+AC:2016, EN 1854:2010 |
| Strain relief torque | 65 Ncm |
203.90 EUR
185.36EUR
in stock · 5
incl. 21% VAT · 153.19 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
The Kromschroder DL5A-3Z is a diaphragm pressure switch designed to regulate positive, negative, or differential air and flue gas pressures. It features a glass fibre reinforced PBT plastic housing with low gas release and a tempered LSR diaphragm system. The switch is rated for safety class II to VDE 0106-1 and its micro switch complies with EN 61058-1. It has a designed lifetime of 10 years and meets standards EN 13611:2015+AC:2016 and EN 1854:2010. The product weighs 254 g and has a cover screw torque of 65 Ncm.
Further details
| Gas type | air or flue gas, no flammable gases, no aggressive gases |
|---|---|
| Production surveillance | Annex II paragraph 3, Annex III paragraph 3 |
All specifications
| Body material | glass fibre reinforced PBT plastic |
|---|---|
| Weight | 254 g |
| Cover screw | 65 Ncm |
| Socket | 65 Ncm |
| Low gas release | yes |
| Construction type | diaphragm pressure switch |
| Micro switch standard | EN 61058-1 |
| Safety class | II to VDE 0106-1 |
| Diaphragm system | tempered LSR diaphragm system |
| Designed lifetime | 10 years |
| Standards | EN 13611:2015+AC:2016, EN 1854:2010 |
| Strain relief torque | 65 Ncm |
Part numbers
| SKU | 84447478 |
|---|---|
| Additional article | 624.214.164 |
| Model | DL5A-3Z |
| Type designation | CE-0085AP0466 |
