Kromschroder Connecting set for two DG..U 74912250
SKU 74912250
Brand Kromschroder
Photos
Key specifications
| Application | gas burners and boiler houses |
|---|---|
| Weight | 6 g |
| Compatibility | DG..U, DG..T |
| Materials | gas-resistant polymers and seals |
11.01 EUR
10.01EUR
in stock · 1
incl. 21% VAT · 8.27 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
Kromschroder connecting set for two DG..U pressure switches, SKU 74912250, is a mounting kit for paired installation of two pressure switches from the DG..U or DG..T series. It enables monitoring of minimum and maximum inlet pressure on a single process unit, creating a logical AND chain for safety circuits. The set weighs 6 g and is made of gas-resistant polymers and seals. It is compatible with Kromschroder DG..U and DG..T pressure switches and is used in gas burners and boiler houses.
Further details
| Advantage | compact installation: replacing two separate units with piping connections with one dual solution, saving space in the cabinet |
|---|---|
| Function | create a compact dual pressure monitoring unit |
| Installation | controlled gas pressure is supplied to one inlet fitting; through internal channels, pressure is simultaneously applied to both installed switches |
| Output signal connection | output signals from the pressure switches are connected in series in the safety circuit |
| Purpose | mechanical and pneumatic connection of two pressure switches |
Choosing and fitting
Parts of this type are selected by matching the pressure switch series and the required connection configuration. Before ordering, verify the pressure switch models (DG..U or DG..T) and ensure the kit's fittings align with the switch ports. Installation involves connecting the gas pressure to the kit's inlet, which distributes pressure to both switches. The output signals from the switches are then wired in series in the safety circuit.
Fits equipment
Kromschroder DG..UKromschroder DG..T
All specifications
| Application | gas burners and boiler houses |
|---|---|
| Weight | 6 g |
| Compatibility | DG..U, DG..T |
| Materials | gas-resistant polymers and seals |
Part numbers
| SKU | 74912250 |
|---|---|
| Additional article | 624.391.003 |
