Brahma Solenoid coil BE6*GFD 18811191

This electromagnetic solenoid coil is for the Brahma BE6*GFD gas valve. It operates at 230 V AC with a frequency of 50–60 Hz and consumes 20 W. The coil has protection class IP40 and insulation class A. It mounts on the valve body and converts an electrical signal into magnetic force to open or close the valve. Net weight is 0.43 kg, gross weight 0.465 kg.

Coils of this type are selected by matching the valve series and manufacturer. The supply voltage must match the burner control output, commonly 230 V or 24 V AC/DC. Check that the coil connector fits the valve stem and that the coil is from the same valve family to ensure correct magnetic force and opening characteristics. The coil is mounted on the valve body and can be replaced separately, reusing the existing valve body.

Coil burnout is a common failure, often caused by prolonged voltage spikes, overheating from the valve body, or a shorted winding. Symptoms include the valve failing to open or close, leading to burner shutdown or ignition failure. Check the coil for obvious burn marks, measure its resistance, and verify the supply voltage.
